VR-110P

Single ten inch active performance linear (neodymium magnetic)

In the high-frequency part, the Wavefront conversion device with mature technology is used, and the original Wavefront conversion device is further optimized to increase the upper limit frequency of high-frequency, reduce distortion, and improve the sense of hearing. The tweeter unit is composed of two composite diaphragms with a diameter of 44MM and a 1-inch throat neodymium magnetic compression driver. The diaphragms are treated with the latest technology, and the pure titanium diaphragm has excellent transient performance and stable continuous output power. Combining low distortion Myla edges for a more natural listening experience.

Product Characteristics

■ In the high-frequency part, the Wavefront conversion device with mature technology is used, and the original Wavefront conversion device is further optimized to increase the upper limit frequency of the high-frequency, reduce distortion, and improve the sense of hearing ■ The tweeter unit is composed of two composite diaphragms with a diameter of 44MM and a 1-inch throat neodymium magnetic compression driver. The diaphragms are processed with the latest technology, and the pure titanium diaphragm has excellent transient performance and stable continuous output power. Combining low distortion Myla edges for a more natural listening experience ■ Mid low frequency is a mid low frequency driver with a voice coil diameter of 75MM and a high output. It is loaded with the latest patented ACPD (Acoustic Correction Passive Driver) to improve the available output of the mid low frequency driver, increase sensitivity, improve sound pressure level and directionality, and increase the horizontal and vertical frequency division points of the speaker's bass drive unit ■ The improved pendant has a higher Factor of safety while reducing the weight of the box. It can suspend up to 16 speakers, and has a 7:1 Factor of safety. The various hanging installation methods greatly expand the use of speakers.

Parameter

Single Ten Linear Speaker Parameters:
Treble: 1.75"×2,44φ high-performance neodymium tweeter driver Bass: 10"×1, high-performance neodymium high power in and out waterproof basin bass Rated impedance: 16Ω
Frequency Response: 65Hz~20kHz (±3dB) Rated Power: 500W
Program transient maximum power: 2000W
Maximum sound pressure level: 132dB
Sensitivity: 99dB (1m/1W)
Directivity: 120º&80ºV×10ºH Wiring type: NEUTRIK NL4MP×2 1+1-;                            Hanging hardware: aluminum metal hanging parts
Box structure: inverted phase;
Size (HxWxD): 280×536×421mm
Weight: 20KG

Single eighteen active subwoofer parameters:
Woofer: 220 magnetic 100 cores x 1, aluminum tray,
Frequency response: 35Hz~250Hz,
Rated power: 800W, peak power 3200W;
Sensitivity 102dB, impedance: 8Ω, maximum sound pressure 137dB,
Box structure: inverted phase;
Wiring form: NEUTRIK NL4MP×2 1+1-;                                                Hanging hardware: aluminum metal hanging parts
Box size(HxWxD):675X510X775(mm);
Weight: 45KG.
